Chamberlain Garage Door Opener Keypads

Check the Learn button color on your opener. If it’s orange/amber or purple, a modern Security+ keypad will work.

Yes. Even if your original keypad is discontinued, current Chamberlain keypads are backwards compatible with most Security+ models.

Press the Learn button on your opener, enter your desired PIN on the keypad, then press enter. The opener light will blink to confirm programming.

Some universal keypads can control multiple doors, but most Chamberlain-branded models are programmed to operate one opener at a time.

• Models 140, 150, 240, 350, 450, 550 (1984–1989)
  → Keypad: ❌ Not available
• Models 700WHC, 701WHC, 1000, 2000, 4000, 4001, 5000 (1990–1992)
  → Keypad: 387LM (works only with yellow, white, gray, or green learn buttons)
• Models 710WHC, 711WHC, 1100, 2100, 4100, 5100, 7200, 8100, 8100M, 4600, CSO (1993–1997)
  → Keypad: 387LM
• Models 1200, 2200, 4200, 6200, 7220, CG40, PD210, PD610, PD612K, 7320, 8200, 9200, 4620, 4640, 9902, PD420, PD460-2, 9950 (1997–Apr 2005)
  → Keypad: 877MAX

• Dip switch remotes (8–9 switches, red LED)
  → Keypad: 387LM
• Billion Code (green LED)
  → Keypad: 387LM
• Rolling Code Security+ (orange/amber LED or learn button)
  → Keypad: 877MAX
• Rolling Code Security+ (purple learn button, no LED)
  → Keypad: 877MAX
